Generators
Huter DY6.5A
| Rated AC frequency, Hz | 50 |
| Guarantee | 1 year |
| Generator type | Synchronous, brush |
| Power factor | 1.0 |
| Oil consumption, g/kWh | ≤6 |
| Number of cylinders | 1 |
| Number of cycles | 4 |
| Ignition system | Magneto |
| Fuel supply system | Free drain (gravity flow) |
| Cooling method | Air forced |
| Spark plug type | F6TC, F7TC and similar |
| Supply system | Carburetor |
| Air filter type | Porous polyurethane |
| Lubricating oil type | SAE 10W-40 API: SL, SJ, SF |
| Type of lubrication system | Splashing in the crankcase |
| Fuel consumption, g/kWh | 325 |
| Launch method | Recoil/electric starter for LX / Automatic for ATS |
| Fuel tank capacity, l | 22 |
| Lubrication system capacity, ml | 1100 |
| Maximum power, W | 5000 / 5500 |
| Brand | Huter |
| Gross weight, kg | 74.5 |
| Dimensions, cm | 69/52.5/55 |
| Rated voltage, V | 220 |
| Packing dimensions | 0.71 × 0.56 × 0.52 m |
| Weight, kg | 73.3 kg |
